Digital Mini Coating Thickness Gauge CM-8855 Car Paint Thickness Meter

1.0 Pieces
MOQ
$415.00(1 - 59 Pieces) $390.00(>=60 Pieces)
prezzo
Digital Mini Coating Thickness Gauge CM-8855 Car Paint Thickness Meter
Caratteristiche Galleria Descrizione di prodotto Richieda una citazione
Caratteristiche
Specificazioni
Warranty: 1 year
Customized support: OEM, ODM, OEM
Model Number: CM-8855
Product name: Coating/film Thickness Gauge
Operating Conditions: Temp. 0~40 °C, Humidity: 10~90 %RH
Min. Measuring Area: 6 mm
Min. Sample Thickness: 0.3 mm
Accuracy: ± 1~3%n or ± 2.5 um
Min. Radius Workpiece: convex 1.5 mm / concave 25 mm; NF: convex 3 mm / concave 50 mm
Resolution: 0.1 um / 1 um
Power Supply: 4 x 1.5 V AAA (UM-4) Battery
Certificazione: ce
Informazioni di base
Certificazione: ce
Model Number: CM-8855
Termini di pagamento e spedizione
Packaging Details: The carton packaging
Supply Ability: 100000 Piece/Pieces per Month
Descrizione di prodotto
Product Description
Operating Principle
Magnetic Induction / Eddy Current (F / NF)
Measuring Range
0~1250 um / 0~50 mil
Resolution
0.1 um / 1 um
Min. Radius Workpiece
F Type: convex 1.5 mm / concave 25 mm
NF Type: convex 3 mm / concave 50 mm
Min. Measuring Area
6 mm
Min. Sample Thickness
0.3 mm
Accuracy
± 1~3%n or ± 2.5 um
Metric / Imperial
Convertible
Battery Indicator
Low Battery Indicator
Operating Conditions
Temp. 0~40 °C, Humidity: 10~90 %RH
Power Supply
4 x 1.5 V AAA (UM-4) Battery
Dimensions
126x65x35 mm
Weight
81 g (Not Including Batteries)
(1) Applications: The F probes measure the thickness of non-magnetic materials (e.g. paint, plastic, porcelain enamel, copper, zinc, aluminium, chrome etc.) on magnetic materials (e.g. iron, nickle etc.) . often used to measure the thickness of galvanizing layer, lacquer layer, porcelain enamel layer, phosphide layer, copper tile, aluminium tile, some alloy tile, paper etc.The N probes measure the thickness of non-magnetic coatings on non-magnetic metals. It is used on anodizing, varnish, paint, enamel, plastic coatings, powder, etc. applied to aluminum, brass, non-magnetic stainless steel, etc. (2) Features: * Can store the new data in 99 groups. * Two measurement mode: Single and Continuous * Metric/imperial system selectable. * Separate Type can provide several type probe, measure can be more flexibility. * Integral Type suitable for single-hand operation, large probe with large contact surface have better stability, users can get continuous, good repetitive and precise measurements.

* Two measuring methods: magnetic induction (F) and eddy current (N).
* Auto memory of calibration value,and auto recognize the substrate.
* Operation process have buzzing reminder,while no buzzing in continuous mode.
* Use “USB data output” and “RS-232 data output” to connect with PC.
* Provide “Bluetooth ™ data output” choice.
* Manual or automatic shut down.
